Technical Specification
Modular linear manifolds with ways provided of stop cocks.
Available with 2, 3, 4, 5 or 6 pipe connections for multilayer pipe.
Manufacturer: TIEMME (Italy)
Material: CW617N-EN12165 brass
O-ring: Nitrile Rubber EPDM
Washer: Nitrile Rubber NBR
Handle: ABS white
Diskette marks use: ABS red/blue
Maximum temperature: 110°C
Minimum temperature: -20°C
Maximum operating pressure: 16 bar
Threads: female ISO 228 parallel
male ISO 228 + o-ring
Together with fittings for multilayer pipe Ø16×2,0
ADVANTAGES:
- Easy assembly
It does not require specialized tools
No connections in the floor
Equal pressure in all sections
- Replaceable head valve
Possibility of extension with additional sections
- Plastic markers of connected devices
The distribution manifolds are tipycally used for hot and cold water distribution. Due to the configuration they may be used to distribute cold/hot water in parallel reducing at minimun the pressure drop. The manifolds are produced according to the relevant rules and are certified for material chemical composition and dimensional request.
The valves have a special insert on the caps that enable the marking of hot or cold water with the appropriate color, as well as the symbol of the receiver (washbasin, toilet, bathtub, shower, washing machine, bidet, heater). You choose the tags yourself – when buying, please provide them in the message to us. Otherwise, we will send them randomly.
The compounds of iron, calcium and other minerals present in the water make the fittings vulnerable to damage due to scale build-up in the tap water system. This often leads to the need to replace elements of the installation, and often entire devices. In the case of TIEMME manifolds, we have the option of replacing the valve heads on each of the water circuits separately. This ensures a long service life of the manifold once purchased.
Replacing the valve head in the manifold:
